Untuk mengukur ketebalan lapisan cat pada permukaan Ferrous dan Non-Ferrous
Measuring principle: magnetic induction (Probe F), Eddy current (probe NF)
Measuring range: 0 to 1300 um (0 to 51.18mils) (Probe F and NF)
Accuracy: ± (3%+2um) , (Probe F and NF)
Resolution: 0 um - 99.9um (0.1um) ; 100um - 999um (1um) ; 1000 um - 1300um (0.01mm)
Calibration: one point to four point calibration, zero point calibration
Data group: one direct group (reading not be stored to memory), four general group (reading will be stored a automatically), Note: each group have individual statistics, alarm limit settings and multi-point calibration
Statistics: no. of readings, mean, minimum, maximum and standard deviation
Units: um, mm, mils
Computer interface: download data via USB
Power supply: two 1.5V AAA battery
Operation environment: temperature (0-40˚C); humidity: 20 to 90% rh
Storage environment: temperature: -20 to 70˚C
Standard compliance: ROHS CE WEE
Size: 110 x 53 x 24 mm
Weight: aprox. 84g
