ASTM D-1559 AASHTO T-245
For determining the resistance to plastic flow of cylinder specimen of bituminous
paving mixture loaded on the lateralsurface by means of the marshall apparatus.
BI-321 Compression Machine Steel frame, electric, 220 V-AC, 1/ 2 HP, 1 Phase, speed: 2 " per minute 1 Set
BI-322 Compaction Mold Machined steel, galvanized, 4 " dia., 3 " height, with collar and base plate 1 Set
BI-323 Stability Mold Cast alumunium, split type 4 " i.d., 4 " wide1 Set
BI-324 Compaction Hammer Machined steel, galvanized, 10 lbs, hammer weight, 18 " drop height 1Set
BI-326 Compaction Pedestal Wooden base with steel platen 1 Pc
BI-327 Compaction Mold Holder Machined steel, quick clamping system 1 Set
BI-328 Extruder Steel frame, hydraulic system 1 Set
BI-329 Flow Meter Cast alumunium, clamping bolt, with dial indicator 30 x 0.01 mm 1 Set
GE-200 Water Bath Stainless steel, water heater 220 V-AC, thermostat 30-85oC 1 Set
GE-101.6 Proving Ring 6000 lbs capacity 1 Set
Dimension ( l x w x h) : 67x50x100cm
Gross Weight: 200 kg
