ASTM D-2850
Consist of :
SO-600.1 Triaxial Compression machine
CD or UU & CU, capacity 300 kgf, loading speed 0.00 to 3.00 mm per minute,
cell ( speciment) size 35mm and 50mm maximum, Control power on-off
switch, fast advanced selector swith.
Variable speed, hand-operated and motorized operated with electric
consumption 220V AC/ 200 W
SO-600.2 Load Measuring; load ring 300 kgf capacity ( 1 pc)
supplied with calibration certificate by Komite Akreditasi Nasional ( KAN) LK-011-IDN
SO-600.3 Displacement Measuring; dial gauge 30 mm x 0, 01mm ( 1 pc)
SO-600.4 Panel Control ( 1 set)
Consist of :
SO-600.4.1 Measuring Pore Pressure, 10 Kg/ Cm² , digital reading for pore pressure value ( 1 pc)
SO-600.4.2 Measuring Cell Pressure, manometer 10 Kg/ Cm² ( 1 pc)
supplied with calibration certificate by Komite Akreditasi Nasional ( KAN) LK-011-IDN
SO-600.4.3 Measuring Back Pressure, manometer 10 Kg/ Cm² ( 1 pc)
supplied with calibration certificate by Komite Akreditasi Nasional ( KAN) LK-011-IDN
SO-600.4.4 Burrete, for measuring pore presssure ( 1 pc)
SO-600.4.5 Top Water Tank, plastic 3 litre cap ( 1 pc)
SO-600.4.6 Buttom Water Tank, stainless steel, 5 litre cap ( 1 pc)
SO-600.4.7 Vacuum Tank, stainless steel ( 1 pc)
SO-600.5 Triaxial Cells ( Cell Chamber)
Consist of :
SO-600.5.1, Chamber, made of non corossive material and acrilyc transparent ( 1 pc)
SO-600.5.2, Sample Pad, for 35mm diameter speciment ( 1 pc)
SO-600.5.3, Sample Pad, for 50 mm diameter speciment ( 1 pc)
SO-600.6 Constant Pressure ( 1 set)
Consist of :
SO-600.6.1 Air Regulator; for cell pressure ( 1 pc)
SO-600.6.2 Air Regulator; for back pressure ( 1 pc)
SO-600.7 Compressor Unit, 0-10 Kg/ Cm² ( 1 set)
SO-600.8 Vacuum Unit, vacuum pump 0-70 cmHg, rotary type, 220 V-AC, ½ HP, 1 Phase ( 1 set)
SO-600.9 Placing Tool, O-Ring 50 mm diameter ( 1 set)
SO-600.10 Placing Tool, O Ring 35 mm diameter ( 1 set)
SO-600.11 Suction Membrane Device, stainless stell, 50 mm diameter ( 1 set)
SO-600.12 Suction Membrane Device, stainless stell, 35 mm diameter ( 1 set)
SO-600.13 Two Ways Split Former, 50 mm diameter ( 1 pc)
SO-600.14 Two Ways Split Former, 35 mm diameter ( 1 pc)
SO-600.15 Sample Tube, stainless steel, 50 mm diameter ( 1 pc)
SO-600.16 Sample Tube, stainless steel, 35 mm diameter ( 1 pc)
SO-600.17 Membrane, rubber, 50 mm diameter ( 10 pcs)
SO-600.18 Membrane, rubber, 35 mm diameter ( 10 pcs)
SO-600.19 Membrane Sealing Ring, ring rubber 50 mm ( 4 pcs)
SO-600.20 Membrane Sealing Ring, ring rubber 35 mm ( 4 pcs)
Overall dimension : 200 x 160 x 80 cm.
